Description
Table Size 14″ W X 25″L
Grinding Width Capacity, Max. 15″
Grinding Length Capacity, Maximum……… 30″
Height Under 14″ Grinding Wheel……….. 18″
Grinding Wheel, Maximum Diameter………. 14″
Grinding Wheel, Width………………… 1-1/2″
Grinding Wheel, Hole Diameter…………. 5″
Grinding Spindle Speed……………….. 1750 RPM
Longitudinal Table Feeds, Range……….. 0 to 100 FPM
Longitudinal Table Travel…………….. 41-1/2″
Cross Table Travel…………………… 13-3/4″
Throat Depth………………………… 17-1/8″
Grinding Wheel Spindle Motor………….. 7-1/2 HP
Overall Dimensions, W x D…………….. 147″ x 104″
Overall Height………………………. 103″
Weight, Approximately………………… 8700 LBS.
Equipped
Category
FOB
Price
Model
Serial Number
CALL TODAY TO INQUIRE
806-762-6504
Product Inquiry
ALL SPECIFICATIONS SUBJECT TO VERIFICATION
SELLER DOES NOT WARRANT THAT USED MACHINERY/EQUIPMENT
COMPLIES WITH O.S.H.A SAFETY STANDARDS. THEREFORE,
COMPLIANCE BECOMES THE RESPONSIBILITY OF THE BUYER.
